EuroGuard Flatform

EuroGuard Flatform Welded Mesh

Specify Us

Download detailed and specific drawings and diagrams of this product.

EuroGuard Flatform | Welded Mesh Panel

Double horizontal wire welded mesh panel

Image Gallery

EuroGuard Flatform panels have a flat profile with double horizontal wires. It is ideal for light commercial sites or similar installations; anywhere durability and security are important. The panels can be stacked above one another to give a 6m high fence.


Dwg files available for this product on request

  • Welded mesh panels 200 x 50mm wire centres
  • Unique vandal-proof panel to post fixing
  • Strong anti-climb design
  • Available in either Medium (double 6mm wire) or Heavy (double 8mm wire)
  • Mesh spacing conforms to Building Regulations for anti-trap
  • Can be stepped to accommodate sloping ground
  • Posts can be adapted to add our security toppings for extra security
  • Conforms to BS EN 1722-14

    Specification to open mesh steel panel fences

  • Matching gates available
Options
  • Decorative topper panels; concave, convex and wave topper panels

Finishes

  • Posts are galvanized to BS EN 1461 as standard
  • Posts galvanized and powder coated to BS EN 13438 in one of our standard colours at extra cost
  • Panels are Jakcoate zinc alloy coated as standard
  • Panels powder coated to BS EN 13438 in one of our standard colours at extra cost
  • Powder coating of panels and posts to any other BS or RAL colour to special order

    • Standard dimensions (heights above 2.43m will be stacked panels)

    Height
    		Width
    		Post Dimensions
    		Mesh: Medium
    		Mesh: Heavy
     1.03m  3.0m 60 x 40mm
    		  double 6mm wire, 5mm vert. wire
     1.23m  3.0m 60 x 40mm
    		  double 6mm wire, 5mm vert. wire
     1.83m  3.0m 60 x 40mm  double 6mm wire, 5mm vert. wire
     2.03m  3.0m 60 x 40mm  double 6mm wire, 5mm vert. wire  double 8mm wire, 6mm vert. wire
     2.43m  3.0m 80 x 60mm  double 6mm wire, 5mm vert. wire  double 8mm wire, 6mm vert. wire
     3.0m  3.0m 80 x 60mm
    		  double 6mm wire, 5mm vert. wire  double 8mm wire, 6mm vert. wire
     4.0m  3.0m 80 x 60mm  double 6mm wire, 5mm vert. wire  double 8mm wire, 6mm vert. wire
     5.0m  3.0m 80 x 60mm  double 6mm wire, 5mm vert. wire  double 8mm wire, 6mm vert. wire
     6.0m  3.0m 80 x 60mm  double 6mm wire, 5mm vert. wire  double 8mm wire, 6mm vert. wire

    Download Line Drawings, Q40s and CAD Files
