Decorative metal railings with optional finials

Barbican Imperial® Residential | Metal Railings

Jacksons Barbican Imperial® railings are the perfect feature to a residential project, offering an aesthetically pleasing metal railing design with a smaller pale pitch at 119mm than our Barbican Imperial® fencing.

Barbican Imperial® Railings correspond(s) to the generic component/material "steel" in the BRE Global Guide online generic specification(s) "Galvanised steel railings" which achieve(s) a summary rating of B within commercial, domestic, residential, health, industrial, education.

25 year service life guarantee

Barbican Imperial® Features

  • Standard height 1000mm and 1250mm
  • 119mm pale pitch
  • 19mm pales
  • Panels can be manufactured to accommodate sloping ground
  • Flat top pales as standard
  • Matching single leaf and double leaf gates available

Panels

Barbican Imperial® Residential panels are up to 1250mm high and have two horizontal hollow sections rails 50 x 25mm. Vertical rectangular hollow section 19mm pales are passed through the rails with standard spacing at 100mm centres. Pales can have added finials for a decorative finish.

Gates

Matching single leaf and double leaf gates available.

Barbican Imperial® Residential Specifications

Height (mm) Post Centres (mm)
Post Dimensions (mm)
Overall Post Length (mm)
1000 3000 60 x 60 1600
1250 3000  60 x 60 1850

Post Options

  • Over length set in concrete as standard
  • Base plated to bolt down onto concrete
  • Cranked to suit wall mounting

Standard Finishes

  • Hot dip galvanised to BS EN ISO 1461 as standard
  • Hot dip galvanised and powder coated to BS EN 13438
  • Marine coat for installations within 500m of salt water or an estuary

Standard Colours

  • Black RAL 9005
  • Green RAL 6005
  • Other colours are available on request
