LPS 1175 Security Rated steel fencing

Sentry® A1 (SR1) Fencing | Steel Security Fencing

Jacksons Sentry® A1 system offers a security rated vertical bar stopped pale-through-rail solution with a flat top which provides a surface suitable for a wide variety of security toppings. It’s simple minimalist design is equally appropriate for contemporary or more traditional settings and is a great alternative to traditional physical security measures whilst providing improved boundary security.

25 year service life guarantee

Enquire about this product

Get a quote for this productSpecify Us
Comparison tool list

Compare this product

Use our comparison tool to help you compare features, applications, heights and finishes of this product with our wider product range.

Sentry SR1 Features

  • LPS 1175 A1 (SR1) Approved
  • Secured by Design Preferred Specification
  • Seamless, concealed vandal proof rail to post fixings
  • Fully welded pale-through-rail construction
  • Anti climb design
  • Double row of 25mm high sharp-pointed steel double comb fro additional security comes as standard
  • SR1 gates available

LPCB product page logo banner


Sentry® A1 panels are up to 3000mm high have two rectangular hollow section rails 60 x 40mm (3 rails if 3000mm high). Vertical round hollow section 32mm pales are passed through the rails with standard spacing at 129mm centres. Panels from 1800mm high have a security comb (double row of sharp steel points 23 x 2mm thick).


A1 gates available.

Sentry A1 Panel Specifications

Height (mm) Post Centres (mm)
Post Dimensions (mm)
Overall Post Length (mm)
1800 3000 60 x 60 2500
2000 3000 60 x 60 2800
2500 3000 80 x 60  3300
3000 2484  80 x 60  3800

Post Options

  • Overlength set in concrete as standard
  • Baseplated to bolt down onto concrete
  • Cranked to suit wall mounting
  • Standard Finishes
  • Hot dip galvanised to BS EN 1461 as standard
  • Hot dip galvanised and powder coated to BS EN 13438 in one of our standard colours at extra cost
  • Powder coating to non standard BS or RAL to special order
  • Marine coating for applications near sea water (optional extra)
  • Explore our finishes below


    Standard Colours
  • Black RAL 9005
  • Green RAL 6005
  • Grey RAL 7012
  • Blue BS 20-C-40
  • Blue RAL 5010
  • Red RAL 3020
  • Yellow RAL 1018
  • Brown RAL 8017
  • White RAL 9010
  • Other colours are available on request

  • Standard powder coating colours:

    RAL colours steel fencing

    Document Downloads

    Download specification documents, drawings and case studies for this product

    LPS 1175 A1 fencing

    About A1 (SR1) Fencing

    A1 fencing has been tested and certified to provide the minimum level of protection against opportunistic attacks after undergoing the LPS 1175 test devised by LPCB. During testing our fencing had to delay several attacks using category A tools such as screwdrivers, pliers, and small knives, each lasting at least 1 minute, providing it with a rating of A1 under Issue 8, the equivalent of SR1 under Issue 7. Find out more and view the full product range here.
