LPS 1175 Security Rated welded mesh panel with timber slats

EuroGuard® Combi A1 (SR1) | Security Rated Mesh Panel Fencing

EuroGuard® Combi LPS 1175 A1 fencing brings our unique experience and reputation in steel and timber fencing and gates together in a design that combines natural wooden slats with the strength of steel mesh. The combination of welded mesh panels and closely spaced, substantial timber slats provide a flat facing surface ensuring no foot or hand holds, perfect for sites requiring a natural timber façade or where privacy is important. EuroGuard®Combi A1 meets the guidance within ‘Physical Mitigation’ measures issued by the National Counter Terrorism Security Office (NaCTSO) to cover assets from view, making observation into a site more difficult.

25 year service life guarantee

Enquire about this product

Get a quote for this productSpecify Us
EuroGuard® SR1 Features

  • LPS 1175 A1 (SR1) approved
  • Secured by Design preferred specification
  •  Mesh size 200 x 50mm
  • Anti-climb design
  • SR1 gate available



Panels

EuroGuard® Combi A1 panels are 3000mm wide with 200 x 45mm mesh, 5mm wires with 4 - 6 reinforcing folds according to height.


Gates

A1 gates available.

EuroGuard® Combi A1 Panel Specifications


Height (mm) Post Centres (mm)
Post Dimensions (mm)
Overall Post Length (mm)
2070 3034 80 x 60 2800
2470 3034 80 x 60 3300
 3110 3054 120 x 60 + spur post 4000

Post Options

  • Over length set in concrete as standard
  • Base plated to bolt down onto concrete
  • Cranked to suit wall mounting
  • Standard Finishes

  • Hot dip galvanised to BS EN ISO 1461 as standard
  • Hot dip galvanised and powder coated to BS EN 13438
  • Marine coat for installations within 500m of salt water or an estuary
  • Standard Colours

  • Black RAL 9005
  • Green RAL 6005
  • Other colours are available on request
  • Document Downloads

    Download specification documents, drawings and case studies for this product

    Product

    About A1 (SR1) Fencing

    A1 fencing has been tested and certified to provide the minimum level of protection against opportunistic attacks after undergoing the LPS 1175 test devised by LPCB. During testing, our fencing withstood a 10 minute attack from Category A tools such as screwdrivers, pliers and small knives, with each tool given a maximum attack time of 1 minute, providing it with a rating of A1 under Issue 8, the equivalent of SR1 under Issue 7. Find out more and view the full product range here.
