Metal fence railings

Barbican Imperial® Fencing | Security Fencing

Featuring our classic welded pale-through-rail construction, Barbican Imperial® metal fence railings have a less intimidating appearance with 25mm and 32mm diameter round pales (height dependent), with no reduction in strength or security. Barbican Imperial® is available with a choice of decorative finials and post tops to offer the right solution for even the most prestigious applications.

Barbican Imperial® correspond(s) to the generic component/material "steel" in the BRE Global Guide online generic specification(s) "Galvanised steel railings" which achieve(s) a summary rating of B within commercial, domestic, residential, health, industrial, education.

25 year service life guarantee

Enquire about this product

Get a quote for this productSpecify Us

installation-by-jacksons-250-250We provide nationwide installation for all of our security fencing, gates, and acoustic barriers. Installation is carried out by our experienced gangs who have extensive knowledge of our products and install to our premium standards. Let us know if you require installation when you make an enquiry using our product quote form or by calling us.

Barbican Features

  • Posts can be customised for Barbed wire / Razor wire / Rota Spike®
  • Vertical pale spacing conforms to building regulations for anti-trap
  • Unique vandal-proof panel to post connectors
  • Panels can be manufactured to accommodate sloping ground
  • Anti climb design
  • Matching single leaf and double leaf gates available

Product page logo banner no sbd

Panels

Barbican Imperial® metal fence railings comprise of vertical round hollow section 25mm diameter pales up to 2000mm high at 124mm centres (99mm gap) and 32mm for 2100m+ with 129mm centres (97mm gap). Panels under 1200mm come with flat top pales as standard, with an option of a pointed top. Panels 1500mm and above come with pales cut at 45°.

Product

Compare this product

Use our comparison tool to help you compare features, applications, heights and finishes of this product with our wider product range.

Barbican Imperial® Panel Specification

Height (mm) Post Centres (mm)
Post Dimensions (mm)
Overall Post Length (mm)
1000 3000 60 x 60 1600
1250 3000  60 x 60  1850
1500  3000  60 x 60  2100
1800  3000  60 x 60  2500
2000  3000  60 x 60  2800
2500  3000  80 x 60  3300
3000  2484  80 x 60  3800

Gates

We manufacture matching single and double leaf gates for this product, with a range of opening actions and manual and automatic operating options.

Browse Gates
Post Options

  • Overlength set in concrete as standard
  • Baseplated to bolt down onto concrete
  • Cranked to suit wall mounting
  • Standard Colours
  • Black RAL 9005
  • Green RAL 6005
  • Grey RAL 7012
  • Blue BS 20-C-40
  • Blue RAL 5010
  • Red RAL 3020
  • Yellow RAL 1018
  • Brown RAL 8017
  • White RAL 9010
  • Other colours are available on request

  • Standard powder coating colours:

    RAL colours steel fencing
    Standard Finishes
  • Hot dip galvanised to BS EN 1461 as standard
  • Hot dip galvanised and powder coated to BS EN 13438 in one of our standard colours at extra cost
  • Powder coating to non standard BS or RAL to special order
  • Marine coating for applications near sea water (optional extra)
  • Explore our finishes below

    Finishes

    hedgehog-6714346
    this is a hedgehog friendly product

    The pale spacing allows free movement of hedgehogs in search of food, mates, and shelter, which is essential for their survival.

    Applications

    Barbican Imperial

    Finial Options

    Barbican Imperial Finials

    Finials

    Document Downloads

    Download specification documents, drawings and case studies for this product

    Vertical Bar Fencing Range

    We have a wide range of vertical bar fencing, all with a 25 year guarantee. Browse individual products or view the full range below.

    View Range

    Specify this product on NBS Source
